2 Sets MURATEC VORTEX VOSIII 870 Year–2013
$222,999.00
Max Spinning Speed : 500 m/min (Max.)
Yarn Count Range : Ne15–Ne60 (39 tex–10 tex)
Fiber Length : 38 mm (Max.)
Unit Pitch : 235 mm
Traverse Width : 6″
Max Package : Ø300 mm / 3.2 kg (Parallel)
Installed Power (96 Units) : 27.5 kW
Compressed Air : 0.60 MPa; Approx. 80 L/min per nozzle @ 0.5 MPa
Key Features : VOS III, MSC Yarn Clearer, Auto Doffer, Splicer Carriage, Package Conveyor
Condition : Used Very Good
Location : China🇨🇳
Ready for Export:YES
Post Date 24-February-2026
Price Includes Dismantling, Packing & Shipping
Machine : Muratec Vortex III 870 (Vortex / Air-Jet Spinning)
Process : Yarn spun directly from slivers and wound to packages (process integration)
Max Spinning Speed : 500 m/min (Vortex III 870)
Spindles/Units : 96
Material : Cotton 100%, Synthetic/Cotton, Synthetic 100%
Yarn Count Range : Ne15 to Ne60 (39 tex to 10 tex)
Fiber Length : 38 mm (1.5”) max
Sliver Weight : 70 to 35 Grain/yd (5 to 2.5 ktex)
Sliver Can Size : Ø400×H1200 mm (16”×48”) / 2 Lines; Ø450×H1200 mm (18”×48”) / 2 Lines; Ø500×H1200 mm (20”×48”) / 3 Lines; Ø600×H1200 mm (24”×48”) / 3 Lines
Unit Pitch : 235 mm
Total Installed Power (96 Units) : 27.5 kW (with 3 Splicer Carriages)
Traverse Width : 6”
Winding Shape : 0° (Parallel) / 4°20’ / 5°57’
Max Package Diameter : 300 mm
Max Package Weight : 3.2 kg (Parallel)
Splicer Carriage : Type Splicer; Max Carriage 6 Units; Cycle Time 10 sec
Auto Doffer : Doffing Cycle Time 15 sec; Traveling Speed 25 m/min
Bobbin Stocker : 160
Compressed Air (Machine Inlet) : 0.60 MPa (6.1 kgf/cm²); Dew Point 25°C max (at 0.6 MPa); Max Oil 0.07 g/m³; Air Volume Approx. 80 L/min (ANR) per nozzle @ 0.5 MPa
Frame Dimensions (96 Units) : L1 22,560 mm; L2 27,192 mm; Minimum Space Between Frames 2,000 mm
Standard Equipment : VOS III Control Panel; Spinning Sensor; MSC (Muratec Spin Clearer); Friction Roller; Yarn Length Measuring Device; Individual Inverter Drive; Vacuum Chamber with Automatic Waste Fiber Extracting; Package Conveyor; Air Pressure Control Panel
Optional : MSC-F (Foreign Fiber Detector); Waxing Device; Package Lifter; Overhead Blow Cleaner; Splice Monitor; Additional Splicer Carriage; Additional Spindle; Additional Air Piping (Crown Spindle)
Yarn Advantages (Typical Vortex Yarn) : Reduced hairiness and clear appearance; resistance to pilling and abrasion; moisture absorption and wash resistance; stability against deformation
Market Reference (Same Model/Year/Spindles) : Year 2013, 96 spindles, offered as running condition; listings commonly seen in China market
